The Communication Angle Tower is an advanced engineering marvel, tailored for robust support in telecommunications. Crafted from superior quality steel, its angular design provides exceptional strength and stability, ensuring reliable signal transmission across vast distances. This tower is versatile, accommodating a variety of communication technologies, including cellular, microwave, and radio broadcasts. Its design prioritizes both functionality and durability, offering resistance to environmental challenges while maintaining a streamlined appearance. Ideal for expanding communication networks, it represents a pivotal investment in the infrastructure of connectivity.
| No | Item | Data |
| 1 | High | From 60M-100M or according to client's requirement |
| 2 | Use | Mobile phone signal, traffic satellite positioning system(GPS) and other signal transmission and transmission |
| 3 | Shape | Polygonal or Conical |
| 4 | Material | Normally Q235B/355B/420B/420C...Yeild Strength≥235MPa |
| 5 | Q355B,Yeild Strength≥345MPa | |
| 6 | As well as Hot Rolled coil from ASTM572,GR65,GR50,SS400 | |
| 7 | Tolerance of the dimension | According to client's requirement |
| 8 | Surface treatment | Hot-dip-any other standard by client's requirement |
| 9 | Joint of Poles | Slip joint,flanged connected |
| 10 | Manufacturing standard | GB/T2694-2018 |
| 11 | Wind speed design | 30M/s(varies by region) |
| 12 | Standard | SOI9001:2015 |
| 13 | Length of per section | Within 13M once forming |
| 14 | lce depth | 5mm-7mm (varies by region) |
| 15 | seismic strength | Lv.8 |
| 16 | Preferred temperature | -35 degrees Celsius to 45 degrees Celsius |
| 17 | Vertical direction | <1/1000 |
| 18 | Welding Standard | AWS(American welding Society)D 1.1 |
| 19 | Production Process | Raw material test-cutting-bending-welding-dimension verify-flangewelding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages |
| 20 | Packages | according to client's requirement |
| 21 | Life Period | More than 30 years,it is according to installing environment |
Strong structural stability: the communication angle steel tower adopts angle steel as the main structural material, and builds a solid triangular or polygonal frame structure through precise angle cutting and welding technology. This design not only ensures the high stability of the tower, but also effectively resists the influence of wind, earthquake and other natural conditions, guaranteeing the safe operation of communication equipment.
Easy to install and maintain: Due to the standardization and modularization of the structural components of the angle steel tower, it makes its installation process on site faster and more convenient. At the same time, the open design of the tower facilitates the daily inspection and maintenance work, greatly reduces the maintenance cost and time, and improves the stability and reliability of the communication network.
Flexibility and adaptability: the design of communication angle steel tower is highly flexible and can be customized and designed according to different communication needs and geographic environments. Whether it is a busy part of the city or a remote mountainous area, the tower height, tower type and other parameters can be adjusted to meet the specific needs of different environments.
Economy: Compared with other types of communication towers, angle steel towers have certain advantages in terms of material and manufacturing costs. As a common construction material, angle steel is relatively inexpensive and easy to process and manufacture, thus making the construction cost of the whole communication tower more economical and providing a cost-effective solution for communication operators.
